The DelStar Series, heavy duty brushless alternators are an integral charging system of an innovative design. The compact, heavy duty construction provides efficiency and increased service life expected to match the longer maintenance intervals of today’s engines, while providing a performance level without parallel.


DelStar Search


*Alternator RPM

Search Results for:
100-16110

160PAD.jpg    160-DPAD.jpg


Part No. 100-16110 100-16110-D
Series 161 161
Design Brushless Brushless
Mount Pad 80mm Pad 80mm
Volts 12 12
Amps @ 2000 RPM (Rotor) 116A 116A
Amps @ 6000 RPM (Rotor) 200A 200A
Ground Negative Negative
Regulator Internal Internal
Pulley - -
Product Specs. 100-16110 100-16110
Technical Bulletin

The DelStar alternators are extremely efficient and high amperage output. Ensure alternator cables are adequate to handle the alternator output current. Voltage drop between Alternator B+ (Output Terminal) and Battery B+ (Positive Terminal) should not exceed 0.5 Volts drop at full alternator output.

Dimensions:


NOTICE: Specifications and connections provided are believed to be correct at the time of publication. Verify connections before replacing the unit.
